| Typical Throughput |
Medium
Approximately 10–30 cartons per minute, depending on carton size, product arrangement, and loading method.
|
High
Approximately 30–80 cartons per minute when product flow, carton quality, and feeding are consistent.
|
Medium to High
Approximately 15–60 cartons per minute, depending on robot payload, reach, gripping method, and product presentation.
|
Match the machine's sustained output to the required rate, not only its advertised peak speed. Include planned changeovers and short stops in the calculation.
|
| Typical Equipment Footprint |
Compact
Commonly about 2.5–5.0 m long and 1.5–2.5 m wide, excluding conveyors and service clearance.
|
Moderate to Large
Commonly about 4.0–8.0 m long and 2.0–3.5 m wide because of continuous product and carton flow.
|
Variable
Commonly about 3.0–7.0 m long and 2.5–5.0 m wide, including robot guarding, infeed, and pallet or carton accumulation areas.
|
Reserve space for operator access, electrical panels, guarding, carton storage, product accumulation, cleaning, and maintenance—not only the machine frame.
|
| Required Service Clearance |
At least 0.8–1.0 m around operator and maintenance access points is commonly required.
|
At least 1.0–1.2 m is commonly preferred around drives, forming sections, glue systems, and conveyor access points.
|
At least 1.0–1.5 m may be required outside the safety enclosure, depending on robot layout and access-door locations.
|
Confirm clearance against local safety rules, the machine supplier's layout drawing, and the facility's emergency-exit routes.
|
| Product Flexibility |
Good
Suitable for stable products with repeatable dimensions and defined loading patterns.
|
Limited to Medium
Best for uniform products that can maintain consistent spacing and orientation at high speed.
|
High
Better suited to mixed orientations, irregular product presentations, and multiple loading patterns when appropriate tooling and vision systems are used.
|
Test the complete product range, including the smallest, largest, lightest, heaviest, and least rigid items.
|
| Carton Format Flexibility |
Medium
Often supports several carton sizes with format parts and recipe changes.
|
Medium
Can handle multiple formats, but guides, timing, and carton magazines may require more adjustment.
|
High
Format changes can be flexible when the robot program, grippers, and carton-handling equipment are designed for them.
|
Request a written format matrix showing carton dimensions, product patterns, change parts, changeover time, and maximum validated speed.
|
| Changeover Time |
Typically 10–30 minutes
Faster when adjustments are tool-less and recipes control servo positions.
|
Typically 20–45 minutes
More guides, timing points, and carton-flow settings may need adjustment.
|
Typically 10–30 minutes
Programmed changes can be quick, although gripper or fixture replacement may add time.
|
Base the comparison on the complete process, including product recovery, line clearance, cleaning, format-part replacement, and first-good-carton verification.
|
| Routine Maintenance |
Moderate
Requires inspection of belts, chains, bearings, suction devices, sensors, carton guides, and forming mechanisms.
|
Moderate to High
Higher operating speed increases the importance of lubrication, alignment, timing, wear-part inspection, and preventive replacement.
|
Moderate
Includes robot lubrication schedules, end-of-arm tooling checks, vision-system cleaning, sensors, conveyors, and safety-device testing.
|
Ask for preventive-maintenance intervals, recommended spare parts, mean time to repair, remote-support options, and technician training requirements.
|
| Change Parts and Spare Parts |
Common wear parts include belts, grippers, vacuum cups, bearings, sensors, knives, and carton guides.
|
Common wear parts include belts, chains, timing components, carton feeders, glue-system components, bearings, and sensors.
|
Common wear parts include gripper pads, vacuum cups, robot tooling components, camera covers, conveyors, sensors, and safety switches.
|
Prefer standardized components that are locally available and clearly identified in the spare-parts list. Keep critical items for at least one planned maintenance cycle.
|
| Operator Skill Requirement |
Moderate
Operators need training in setup, carton loading, fault recovery, adjustments, and quality checks.
|
High
Operators and maintenance staff need stronger skills in timing, synchronization, high-speed fault recovery, and process control.
|
High
Technicians may need training in robot operation, tooling, vision recipes, safety circuits, and controlled program changes.
|
Evaluate the available workforce, training time, language requirements, documentation quality, and dependence on specialist technicians.
|
| Safety Requirements |
Safety guarding, interlocked access doors, emergency stops, pinch-point protection, and safe pneumatic isolation are required.
|
The same safeguards are required, with additional attention to high-speed moving parts, product ejection, and stored mechanical energy.
|
Requires a risk-assessed safety enclosure, interlocked gates, emergency stops, safe robot motion, restricted access, and validated restart procedures.
|
Require a documented risk assessment, safety-circuit validation, lockout/tagout provisions, accessible emergency stops, and compliance with applicable local regulations.
|
| Noise and Working Environment |
Noise commonly comes from pneumatics, vacuum pumps, chains, and carton handling. Noise levels should be verified during factory acceptance testing.
|
Higher speed may increase noise from conveyors, drives, carton impacts, and compressed-air use.
|
Robot motion may be relatively quiet, but conveyors, vacuum equipment, guarding, and product impacts still affect workplace noise.
|
Specify the allowable workplace noise level, dust conditions, washdown requirements, temperature range, and applicable hygiene standards before design approval.
|
| Utilities |
Usually requires electrical power and compressed air; vacuum may be generated centrally or locally. Typical air demand is highly application-dependent.
|
Usually requires greater electrical capacity and stable compressed-air supply because of higher speed and more actuators.
|
Requires electrical power, compressed air or vacuum for tooling, and sometimes network infrastructure for vision and production data.
|
Confirm voltage, phase, connected load, compressed-air pressure and quality, peak air consumption, vacuum requirements, and utility connection locations.
|
| Line Integration |
Common interfaces include infeed conveyor, product accumulation, carton magazine, case sealer, reject system, and line-control signals.
|
Requires precise synchronization with upstream product spacing, carton erection, downstream sealing, and accumulation equipment.
|
Requires integration of robot control, vision systems, conveyors, product tracking, safety PLC functions, and recipe management.
|
Define signal lists, communication protocols, conveyor speeds, product-spacing rules, accumulation capacity, reject logic, and ownership of line-level controls.
|
| Data and Traceability |
Can provide production counts, fault history, downtime reasons, recipe data, and basic batch or lot information.
|
Often supports detailed speed, stoppage, reject, and performance data when connected to a line monitoring system.
|
Can provide product-recognition results, image or inspection status, robot cycle data, recipe information, and reject records.
|
Specify required data points, retention period, user permissions, time synchronization, network security, and compatibility with the plant's monitoring system.
|
| Best-Fit Production Profile |
Suitable for moderate volumes, frequent format changes, and products requiring controlled handling.
|
Suitable for high-volume production with stable products, consistent cartons, and long production runs.
|
Suitable for mixed products, variable loading patterns, labor-intensive manual packing, and lines where flexibility is more important than maximum mechanical speed.
|
Select the machine type based on the full operating profile: annual volume, shift pattern, product variety, changeover frequency, labor availability, and future expansion plans.
|
| Primary Selection Risk |
The machine may be undersized if actual product variation or required output is higher than the initial specification.
|
The machine may lose efficiency when cartons, products, or upstream spacing are inconsistent.
|
The project may become more complex if tooling, vision, programming, or safety integration is not fully defined.
|
Use representative products and cartons for factory testing. Approve the purchase only after throughput, changeover, safety, integration, and maintainability targets are demonstrated.
|
